Turn-key Electron apps with Meteor

Turn-key Electron apps with Meteor | Mixmax

Last month, we released our first desktop application to rave reviews. After several improvements and the release of the Windows version, we’re pulling back the curtain to reveal how we built the app.

When we decided to make a desktop application, Electron was an easy choice. Using a cross-platform framework would allow us to reach the most users, critical for a business at our early stage. Using a framework based on web technologies would allow us to reuse parts of our web application—and best leverage the talent behind it, in particular our designer’s marvelous HTML and CSS skills. And using a framework based on Chromium would give us access to the same bleeding-edge web APIs we use in our web application in our desktop app.

But with that choice made, there were still a number of questions remaining: how would we…

  • load our web application in Electron?
  • package the app?
  • communicate between the web and native parts of the app?
  • distribute the app?

To answer these questions, we reviewed a ton of Electron documentation, GitHub issues, and prior art. The result is a Meteor package, meteor-electron, that makes it as easy as meteor add quark:electron to get your Meteor application running in a native shell. If you’d like to try it out, head on over to the GitHub repo; but if you’re interested in its development, read on!

Preface

We developed our Electron infrastructure as a Meteor package because the web application we were wrapping was a Meteor application, but the techniques and lessons described below would in large part apply to packaging any web application (using Rails, Django, Express, etc.) as an Electron app.

With that said, Meteor facilitates a particularly smooth workflow in that its packages can hook into the build process, server, and client. As you will see, Electron development requires coordinating changes across all three of those areas.

Meteor in the cloud, Electron on the desktop

We first came across a prototype of meteor-electron when deciding how to load our Meteor app in Electron: remotely or locally? There were several packages that promised to do the latter—build and run Meteor inside the Electron app. But that decision came with limited support for building the app for multiple platforms. The primary advantage of the local approach seemed to be offline support—but we didn’t need that for v1. More important to us was getting a cross-platform app out as soon as possible and being able to quickly iterate upon it. That made the case for loading Meteor remotely even more strongly, since we could use Meteor’s hot code push to update the bulk of the app.

Automatic packaging

We were also attracted to meteor-electron by its focus on ease of use. Where other projects foregrounded customization and build processes, meteor-electron got us started right away. When we added its package to our app, it automatically downloaded the Electron binary for our system, packaged our application, and opened it in a native shell.

The packaging step bears some discussion: the officially-supported way to package an Electron app is to manually edit the contents of the Electron binary! That’s crazy. Under the hood, meteor-electron uses the excellent community project electron-packager to bundle your code and resources. What’s more, meteor-electron uses reasonable defaults for packaging, easily customizable through your Meteor.settings file.

This turn-key packaging was a great user experience, and one that we’ve enhanced working with meteor-electron’s creator, Mike Risse. For instance, we’ve since improved the project to automatically rebuild and relaunch the app when the native code or the application settings change.

Safe native bridge

Once we had our application loading in meteor-electron, we started to consider how we could customize it for the native context. Some simple feature detection APIs were trivial to add thanks to meteor-electron’s ability, as a Meteor package, to load code on the server (like the packaging logic) and the client.

Providing the client with access to native capabilities was trickier. Or should I say, it was too easy: by default, all Node APIs and modules are accessible from web content.

Electron assumes that you will be loading your HTML etc. from disk, and thus views it as a trusted extension of the native code. But this assumption fails disastrously for hybrid native-web applications like Meteor desktop apps.

<script> require('child_process').exec('rm -rf /*'); // Worst XSS attack ever. </script>

Thankfully, it is possible to disable this Node integration when opening browser windows. (Bonus: doing so can fix web dependencies failing to load by incorrectly assuming that they’re running in a CommonJS environment.)

We do still wish to expose certain native APIs to the web content. Luckily, there exists a mechanism for doing so called a “preload script”. This script is loaded before other scripts run in the page; always has access to Node APIs, no matter whether Node integration is turned on or off; and can add symbols to the page’s global scope. With Node integration turned off:

  Native scripts Preload script Browser scripts
Access to Node global context < >
Access to browser global context   < >

This means that the preload script can provide the webpage with indirect access to select Node APIs:





// Local variables will not escape the preload script.
var shell = require('electron').shell;

// Global variables _will_ escape the preload script, except for globals injected by Node,
// like `require`—-those will be deleted after the script is done executing.
Electron = {
  openExternal: function(url) {
    shell.openExternal(url);
  }
  // Notice we don’t save `shell` as a property of `Electron`! Then it’d be available
  // to the webpage.
};
<script> // Successfully uses the `shell` module as prescribed by the preload script. Electron.openExternal('https://mixmax.com/download'); // Logs "Uncaught ReferenceError: shell is not defined(…)" shell.moveItemToTrash('~/Documents'); // (Ignoring previous line) Logs "Uncaught ReferenceError: require is not defined(…)" require('electron').shell.moveItemToTrash('~/Documents'); </script>

meteor-electron’s use of a preload script thus makes it possible for Meteor apps to safely make use of native functionality.

Distribution: to be continued…

You’ve seen thus far how meteor-electron offers Meteor developers a simple and safe path to creating desktop applications. In part 2 of this blog post, we’ll talk about how meteor-electron adds support for distribution, even automatic updates, without developers having to add any server-side code themselves.

Tips for converting webapps to desktop apps? Discuss on Hacker News, tweet us @Mixmax or drop us a line at careers@mixmax.com. You can also come to Meteor Night 1/21 to see Mike and Jeff demo meteor-electron live.

Interested in solving hard problems like this? Come join us at Mixmax.
